ILT-C05
- Product SKU: ILT-C05
- Category: Level Sensors, Sensors, Wika
Wika Stainless steel radar level sensor ILT-C05 Part Number-14797081 is suitable for Water-based, Oil-based, Solid material of Dielectric constant ≥ 2 it is designed for high process temperatures upto 150 deg C
Specifications :
Measurement principle : FMCW (60 GHz technology); frequency band 57.4 ... 61.4 GHz
Measuring range: 100...5000 mm
Beam angle : ±6°
Output signal: 4...20 mA, 3-wire
Power supply: 9...32 V
Load: max. 600 Ohm
Electrical connection: M12 x 1 round plug
Process Temperature : High Temperature version to 150 °C [320 °F]
Pressure limit of medium : 0 … 25 bar [0 … 362 psi]
Process connection: G ½" can be mounted from the outside
Calibration option: empty calibration container situation + Measuring range adjustment (0% at the bottom of the container)
Wika Stainless steel radar level sensor ILT-C05 Part Number-14797081 is suitable for Water-based, Oil-based, Solid material of Dielectric constant ≥ 2 it is designed for high process temperatures upto 150 deg C
Specifications :
Measurement principle : FMCW (60 GHz technology); frequency band 57.4 ... 61.4 GHz
Measuring range: 100...5000 mm
Beam angle : ±6°
Output signal: 4...20 mA, 3-wire
Power supply: 9...32 V
Load: max. 600 Ohm
Electrical connection: M12 x 1 round plug
Process Temperature : High Temperature version to 150 °C [320 °F]
Pressure limit of medium : 0 … 25 bar [0 … 362 psi]
Process connection: G ½" can be mounted from the outside
Calibration option: empty calibration container situation + Measuring range adjustment (0% at the bottom of the container)
View Product Catalog
